Dexter K71-639-00 - Disk Brake Assembly 6,000 lbs Right-Hand
by Dexter
Out of stock
$640.47
SKU: K71-639-00
- Trailer brake assembly makes it easy to upgrade from drum brakes to disc brakes for better performance
- More consistent stopping, even at highway speeds
- Dramatically shorter stopping distance
- Easier and less expensive to maintain
- E-coat finish provides corrosion resistance for freshwater and limited saltwater use
- Vented rotor helps to regulate temperature to prevent overheating
- Included hub replaces your existing hub
- Self-adjusting caliper ensures maximum surface contact for smooth, equal braking
- Semi-metallic brake pads resist heat and provide excellent grip
- Grease cap features removable plug for easy access to grease zerk on E-Z Lube axle
- Ductile iron mounting brackets provide strength and durability
- Weld-on flange sold separately
- Kit includes 1 full brake assembly:
- 1 E-coated rotor
- 1 E-coated hub with bolts pressed in
- 1 E-coated ductile iron caliper
- 2 Semi-metallic brake pads
- 1 E-coated caliper mounting bracket with bolts and nuts
- Bearings, races, grease seal, and E-Z Lube grease cap
- Thread sealant
- Hydraulic brake actuator and lines (sold separately) are required for brakes to be activated
- Requires psi rating of at least 1,600
- Specifications:
- Fits: 6K E-Z Lube axles with 15" to 16-1/2" wheels
- Axle capacity: 6,000 lbs
- Bolt pattern: 6 on 5-1/2"
- Wheel bolt diameter: 1/2"
- Rotor diameter: 12"
- Brake flange configuration: 5 bolt
- Inner bearing: 25580 (1.75" inner diameter)
- Outer bearing: 15123 (1.25" inner diameter)
- Inner race: 25520
- Outer race: 15245
- Grease seal (included): GS-2250DL
- Inner diameter of grease seal: 2.25"
- Outer diameter of grease seal: 3.376"
- Warranty: 5-Year limited warranty
Specifications
| Brand | Dexter |
| Part status | Special order |
